USLPore® is used as an aerated lightweight concrete board for insulation purposes. It fulfills all requirements for a modern insulation material.
Environmentally-friendly manufactured it is an ideal solution to substitute organic insulation materials such as expanded polystyrene (EPS) and polyurethane (PU) or inorganic ones such as mineral wool.
info@uslpore.com
+49-30-23321149-0
True Pore Technology
Innovative technology for aeration of construction materialsfor insulation purposes and
reduction of your carbon dioxide footprint
Insulation Board
![](/site/assets/files/1059/uslpore_insulation_board_cover_422_270.jpg)
USLPore® is applied as an insulation board to subtitute expanded polystere boards as well a mineral wool within an external thermal insulation composite system.
- Thermal conductivity: 0.040 [W/mK]
- Worldwide unique low density 90-120 [kg/m³]
- Fireproofed (totally inorganic)
- Fully recyclable (ordinary construction waste)
- High steam diffusion (no mold / mildew)
Projects
![lithopore gallery](/site/assets/files/1059/uslpore_insulation_board_1_s.jpg)
USLPore® foam concrete as an insulating board can be produced at different densities. The density below is representing the average applied density of our customers for the respective application.
A higher density is resulting in a higher compressive strength but lower insulating effect.
A lower density is resulting in a lower compressive strength but better insulating effect.
All USLPore® products are fully non-combustible.
metric | imperial | |||
entity | value | entity | value | |
dimension | [mm] | 600x400x100 any other possible |
[in] | 24x16x4 any other possible |
density | [kg/m³] | 100-125 | [pcf] | 6.2-7.8 |
thermal | [W/mK] | 0.038 - 0.045 | [R-value per in] | 3.1-3.8 |
compression | [KPa] | 250-350 | [PSI] | 36-51 |
